Answer
Sep 21, 2023 - 11:54 AM
I contacted the vendor and they were not able to supply me with the measurements.
This is the only specifications I can provide for you.
This is the only specifications I can provide for you.
- Tray Size: 18" (457mm)
- Minimum Inside Cabinet Size: 36-1/4" (920mm) Width x 19-3/4" (500mm) Depth
- Minimum Inside cabinet Height: 21-1/2" (545mm)
- Minimum Door Opening (Framed Cabinet): 17-3/4" (450mm)
- Minimum Door Opening (Frameless Cabinet): 18-3/4" (475mm)
- Minimum door opening: 85º
- Maximum load per shelf: 55 lbs.
