Description
The timeless design of the Plymouth works with any style in any room of your home. All of Schlage's front entry door handlesets are precision-engineered, built with a rugged metal, and thoroughly tested to ensure maximum residential security.
- Professional Grade 1 Security Deadbolt
- One-Tool Installation - Installs with just a Phillips screwdriver
- Patented adjustable through-bolt at bottom of handle slides up and down 1-1/2" to accommodate a variety of pre-existing holes.
- Single Cylinder Set: Deadbolt thrown or retracted by key from outside or by inside turn unit. Lower latch retracted by thumbpiece from outside or by inside knob/lever.
- Lifetime limited mechanical and finish warranty. (Exclusion: The oil-rubbed bronze finish is designed to improve over time and change in appearance, creating a living finish through daily use.)
Optional Accessories
Specifications
- Manufacturer:
-
Schlage Lock Company LLC
- Manufacturer Location:
-
Mexico
- Color/Finish:
-
n/a
- Material:
-
solid brass
- Style:
-
traditional
- Type:
-
entry set
- Warranty:
-
Lifetime Limited Mechanical & Finish Warranty
- Width:
-
2-15/16"
- Height:
-
12-1/8"
- Projection:
-
2-5/16"
- California Residents:
-
WARNING: This product can expose you to chemicals including lead and/or wood dust, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Additional:
-
- Backset: Universal Backset latch & deadbolt, Adjusts to 2-3/8" (60mm) or 2-3/4" (70mm)
- Crossbore diameter: Designed to fit in 2-1/8in.(54mm) diameter door face hole (lower), 1-1/2in.(38mm) or 2-1/8in.(54mm) diameter door face hole (deadbolt).
- Edge Bore Diameter: 1" (25mm)
- Door Thickness: Door thickness range: 1-5/8" to 1-3/4" thick (41mm-51mm) standard. Thick door kit available for doors up to 2-1/4" (57mm)
- Center-to-Center Hole Spacing: 5-1/2" standard (4" optional)
- Certification: ANSI A156.36, 2010, Grade 1 Lock
- Latch: Dual Option Latch includes spring latch with 1" x 2-1/4" round corner and drive in faceplates
- Strike: Round corner full lip strikes 1-5/8" x 2-1/4"
